STJH-SINGLE-MGO-ROCK-WOOL-CLEANROOM-PANEL-50-MACHINE

Single MgO Rock Wool Cleanroom Panel 50 mm Machine-Made Wall

Thin composite wall panel with one mineral-board backing layer.

One reinforced side avoids a second board layer.
Continuous formed edges suit regular partition runs.

Request a Quote Browse Products

Product Introduction

A single MgO sheet sits between one steel skin and the rock-wool infill. The opposite face bonds directly to the mineral fiber, creating an asymmetric four-layer machine-made section.

Key Features

One reinforced side avoids a second board layer.
Continuous formed edges suit regular partition runs.

Technical Parameters

Core Material	Rock wool with single MgO liner
Panel Thickness	50 mm
Effective Width	950 or 1150 mm
Steel Facing Thickness	0.3–0.6 mm
Core Density	100–140 kg/m³
Liner Thickness	Approximately 5 mm
Manufacturing	Machine-made
Surface Finish	Coated metal skins
Joint Type	Tongue-and-groove
Customization	Available for the application and operating conditions.

Applications

One-sided reinforced clean partitions
Regular-width production walls

Solutions for Your Application

Only the process face needs additional board backing.

The asymmetric section places the MgO layer on that side.

A thick partition restricts a narrow passage.

The 50 mm build-up provides reinforcement within a slim section.

Available Options

Reinforced face orientation
Custom cut lengths

Planning a Single MgO Rock Wool Cleanroom Panel 50 mm Machine-Made Wall specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
