STJH two-door microcontroller airlock kit with white enclosure, locks and request stations.

STJH-TWO-DOOR-CLEANROOM-INTERLOCK-SYSTEM-MICROCONTROLLER

Two-Door Cleanroom Interlock System Microcontroller Airlock

Select normally locked or normally free two-door sequencing with local microcontroller logic and clean relay outputs.

Selectable idle logic accommodates different entry arrangements.
Busy and alarm outputs distinguish waiting from abnormal door conditions.
Optional delay selection helps coordinate successive releases.

Request a Quote Browse Products

Product Introduction

A dedicated microcontroller supervises two monitored doors and their request inputs. The board uses separate relay contacts for door release, busy indication and alarm signalling, and can be installed in a tamper-switched steel enclosure. Configuration jumpers determine the idle behaviour. The assembled two-door system suits a local airlock where operation should remain independent of Ethernet, while still giving the installer clear connection points for locks and auxiliary indications.

Key Features

Selectable idle logic accommodates different entry arrangements.
Busy and alarm outputs distinguish waiting from abnormal door conditions.
Optional delay selection helps coordinate successive releases.

Technical Parameters

Configured Doors	2
Controller Type	Microcontroller board
Nominal Supply	12 VDC
Idle Selection	Normally locked or normally free
Door Release Contact	Single-pole changeover
Contact Voltage	30 V maximum
Contact Current	1 A maximum
Delay Options	5 or 10 seconds
Enclosure Option	Tamper-switched mild steel
Customization	The enclosure and connected door devices can suit the local access arrangement.

Applications

Personnel airlocks using request-to-exit buttons.
Two-door access groups requiring separate busy and fault outputs.

Solutions for Your Application

Waiting for another door resembles a system fault.

Separate busy and alarm contacts provide distinct indications.

Control hardware may be accessible from a corridor.

Select the steel enclosure with a tamper switch.

Available Options

White powder-coated enclosure.
Normally locked configuration.
Five- or ten-second delay selection.
