STjh hybrid modular operating room with equipment integration openings

STJH-MODULAR-CLEAN-OPERATING-ROOM-HYBRID

Modular Clean Operating Room Hybrid Configuration

A modular hybrid operating room planned around fixed imaging, integrated surgical equipment and multidisciplinary image-guided procedures.

Fixed imaging integration
Multidisciplinary room layout
Coordinated ceiling equipment

Request a Quote Browse Products

Product Introduction

The hybrid model extends the modular wall-and-ceiling platform around a fixed angiography system and compatible surgical table. Ceiling supply units, lights and digital routing are coordinated within one room layout so imaging and operative work can take place without transferring the patient to a separate suite.

Key Features

Imaging-compatible geometry

The room layout reserves movement and service zones for a fixed angiography system beside the operating table.

Integrated equipment ceiling

Lights, supply units and airflow components are coordinated to avoid conflicts over the clinical field.

Digital procedure routing

Video and data pathways can be incorporated into the modular envelope for image-guided teams.

Technical Parameters

Room Construction	Prefabricated modular wall and ceiling elements
Imaging System	Layout compatible with fixed angiography equipment
Operating Table	Integrated imaging-compatible surgical table
Ceiling Services	Supply units, surgical lights and airflow components
Digital Integration	Video, data and equipment routing
Clinical Use	Multidisciplinary hybrid procedures
Wall Surface Options	Hygienic modular metal, HPL or glass elements
Door Arrangement	Configured for equipment and patient access
Primary Specialties	Cardiac, vascular, neurological and image-guided surgery
Customization	Room geometry, imaging interfaces and ceiling services can be developed around the selected clinical equipment.

Applications

Cardiac, vascular, neurological and other image-guided interventions requiring operating-room sterility and fixed diagnostic imaging in one suite.

Solutions for Your Application

Imaging movement, lights and ceiling supply units compete for the same overhead space.Coordinate all equipment movement envelopes within the modular ceiling layout before panel and service positions are fixed.

Separate imaging and surgical rooms increase patient transfers.Use the hybrid suite to combine imaging and operative functions around one compatible table and workflow.

Available Options

Imaging-system interface, table integration, ceiling supply units, digital routing, wall finishes and door clearances can be project-configured.

Planning a Modular Clean Operating Room Hybrid Configuration specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
