STjh 3000 by 2000 mm rectangular laminar-flow canopy with six H14 roof modules and clear curtain perimeter

STJH-LAMINAR-FLOW-CANOPY-3000X2000

Laminar Flow Canopy 3000 × 2000 mm Rectangular

A rectangular softwall canopy designed to follow long benches, linear inspection fixtures and narrow production cells.

3 m long protected span
6 m² rectangular floor area
Positive H14 HEPA downflow

Request a Quote Browse Products

Product Introduction

This 3000 x 2000 x 2350 mm canopy extends clean-air coverage along a three-metre process while limiting depth to two metres. Ceiling clean-air modules deliver H14 HEPA-filtered downflow within clear curtains, producing a positive localized zone. The rectangular geometry is better suited to linear assembly or inspection than the square canopies in the same family.

Key Features

Linear process fit

The elongated plan follows long workbenches and staged assembly sequences without excess side depth.

Visible softwall boundary

Clear curtains define the clean zone while allowing staff to observe the entire line.

Scalable overhead filtration

Clean-air module quantity can be distributed along the three-metre span to suit equipment blockage.

Technical Parameters

Overall Dimensions	3000 W x 2000 D x 2350 H mm
Protected Floor Area	6 m²
Airflow Direction	Vertical laminar downflow
Pressure Mode	Localized positive pressure
Final Filter	H14 HEPA
Published Filter Efficiency	99.97% at 0.3 µm
Wall Material	Clear flexible curtains
Layout	Rectangular linear-process enclosure
Construction	Modular and scalable
Customization	Available based on the intended application and operating environment.

Applications

For electronics assembly, medical-device inspection and research benches arranged in a linear three-metre work cell. Map ceiling modules around tall fixtures to maintain coverage along the full span.

Solutions for Your Application

A square canopy wastes floor area beside a long narrow process.Use the 3000 x 2000 mm rectangle to align the clean zone with the bench length.

Tall fixtures interrupt downflow at points along the line.Position filtration modules and critical operations so wakes do not fall onto downstream work.

Available Options

Select clean-air module coverage, curtain openings, mobile or fixed base, lighting and utility access. The frame can be lengthened or divided around the production sequence.

Planning a Laminar Flow Canopy 3000 × 2000 mm Rectangular specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
