STjh 1200 mm stainless unequal cleanroom door on white with a rectangular window in the broad main leaf and a narrow solid companion leaf.

STJH-UNEQUAL-DOUBLE-LEAF-CLEANROOM-DOOR-1200-STAINLESS-VISION

Unequal Double-Leaf Cleanroom Door 1200 mm Stainless Vision

A stainless-faced unequal door with a main-leaf observation window for visible, compact cleanroom access.

The unpainted metal face avoids a separate paint coating around the observation panel.
The main-leaf window places visibility on the everyday operating side.
An opaque secondary blade preserves a compact auxiliary section.

Request a Quote Browse Products

Product Introduction

304 stainless steel faces give this unequal 1200 by 2100 mm nominal door its exposed metal finish. The 50 mm main blade incorporates a 400 by 600 mm rectangular vision panel made with two tempered panes, while the narrower companion blade remains opaque. Manual swing operation serves routine entry and occasional wider passage. A compatible metal frame surrounds the pair, with a lever lockset providing conventional operation at the principal leaf.

Key Features

The unpainted metal face avoids a separate paint coating around the observation panel.
The main-leaf window places visibility on the everyday operating side.
An opaque secondary blade preserves a compact auxiliary section.

Technical Parameters

Nominal Size	1200 × 2100 mm
Arrangement	Unequal double leaf
Leaf Thickness	50 mm
Face Material	304 stainless steel
Operation	Manual swing
Vision Size	400 × 600 mm in main leaf
Glazing	Two 5 mm tempered glass panes
Frame Options	Aluminum alloy or finished steel
Lock Hardware	Lever lockset
Customization	Available for the intended stainless-surface access route and wall installation.

Applications

Cleanroom access specified with stainless-faced doors.
Hospital support passages requiring observation through the main blade.

Solutions for Your Application

Can the main entry leaf retain a view without glazing the narrow blade?

The rectangular double-glazed light is placed in the principal leaf, leaving the secondary section solid.

Will the external finish match a stainless equipment zone?

The selected facing is 304 stainless steel rather than painted steel.

Available Options

Paper-honeycomb or aluminum-honeycomb infill.
Compatible door closer for the main blade.

Planning a Unequal Double-Leaf Cleanroom Door 1200 mm Stainless Vision specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
