STjh 18 kg/h ultrasonic humidifier with two stainless reservoirs and dual mist outlet groups on white.

STJH-ULTRASONIC-HUMIDIFIER-18KGH

Ultrasonic Humidifier 18 kg/h Dual-Reservoir

A large dual-reservoir ultrasonic system for high-output cleanroom zones using purified water.

18 kg/h mist output
Two stainless reservoirs
1250 W input and 77 kg operating weight

Request a Quote Browse Products

Product Introduction

The 18 kg/h model uses two stainless reservoirs and two driver boards, making its internal hardware materially different from the single-reservoir units. Power input is 1250 W and operating weight reaches 77 kg. The dual water sections support high output and staged operation for large cleanroom zones, while purified-water quality, hygienic drainage and air-side absorption remain essential to prevent mineral or microbial contamination.

Key Features

Dual atomization sections

Two reservoirs and driver boards provide the hardware capacity for the highest output in this series.

Staged large-zone operation

Separate sections can sequence output as humidity demand rises and falls.

Stainless water path

Two corrosion-resistant reservoirs support routine draining and cleaning in controlled facilities.

Technical Parameters

Mist Output	18 kg/h
Power Input	1250 W
Reservoirs	2 stainless steel
Driver Boards	2
Operating Weight	77 kg
Atomization	Dual ultrasonic transducer sections
Feed Water	Purified water
Control	Staged or modulating output
Primary Duty	Large cleanroom humidity zone
Customization	Available based on the intended application and operating environment.

Applications

For large cleanrooms, electronics manufacturing and industrial humidity-control zones with purified-water infrastructure.

Solutions for Your Application

One reservoir operates while the other stagnates during extended low load.Use lead-lag rotation, automatic drain routines and periodic hygiene cycles for both sections.

The 18 kg/h mist rate wets filters or surfaces at low airflow.Interlock output with airflow, use high-limit humidity control and provide adequate mixing and evaporation distance.

Available Options

Confirm water purity, dual-section staging, voltage, mounting capacity, distribution, drain and overflow, hygiene program and BMS alarms.
