STjh 600 by 1200 mm stainless ULPA FFU with twin top intakes and long reinforced filter face

STJH-STAINLESS-STEEL-FFU-600X1200-ULPA

Fan Filter Unit 600 × 1200 mm Stainless Steel ULPA

A full-length stainless steel ULPA module for broad sterile manufacturing and cleanroom ceiling zones.

600 x 1200 mm long-format face
304 stainless steel housing
120 or 240 VAC configuration

Request a Quote Browse Products

Product Introduction

This 600 x 1200 mm ULPA fan filter unit doubles the nominal face length of the square stainless model while retaining cleanable 304 stainless construction. A selectable 120 or 240 VAC supply supports different facility electrical standards. Its larger footprint is intended for broad sterile production zones where reducing ceiling joints is useful, provided the grid, lifting route and service access are designed for the long module.

Key Features

Broad sanitary coverage

The long ULPA face supplies a larger clean zone while maintaining a wipeable stainless enclosure.

Fewer module boundaries

One full-length housing can reduce the number of ceiling joints and separate service points across a production bay.

Selectable facility voltage

The electrical package can be configured for 120 or 240 VAC to match the available supply.

Technical Parameters

Nominal Module Size	600 x 1200 mm
Housing Material	304 stainless steel
Final Filter	ULPA
Power Supply	120 or 240 VAC
Airflow Direction	Vertical filtered-air supply
Fan Control	Operating point adjusted to the installed filter and room duty
Filter Seal	Selected for the required room-side or top-side service arrangement
Installation	Full-perimeter supported rectangular ceiling mounting
Surface Care	Cleanable stainless exterior for compatible disinfectant procedures
Customization	Available based on the intended application and operating environment.

Applications

Recommended for sterile manufacturing suites, biotechnology production, large medical-device clean zones and other areas needing broad ULPA-filtered coverage with a stainless exterior. Return-air capacity and service access must be checked for the larger supply face.

Solutions for Your Application

Multiple square units create extra seams and cleaning interfaces over a broad sterile zone.Use the 1200 mm long housing where the ceiling can support one larger cleanable module.

The available facility voltage differs between installations.Select the 120 or 240 VAC electrical configuration before manufacture and coordinate the local isolator.

Available Options

Confirm voltage, control method, ULPA filter and seal, service side, stainless finish and full-perimeter support. Final airflow remains subject to the installed pressure and room balance.

Planning a Fan Filter Unit 600 × 1200 mm Stainless Steel ULPA specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
