STjh 80 cubic foot three-bay pass-through refrigerator with three front glass doors and nine shelves

STJH-REFRIGERATED-PASS-BOX-80CUFT-2TO8C

Refrigerated Pass Box 80 cu ft Straight-Through

A three-bay 2265 L refrigerated cabinet for high-volume material transfer and organized access from both sides.

2265 L maximum series capacity
Three access bays per face
Nine-shelf organization

Request a Quote Browse Products

Product Introduction

The 80 cu ft model uses a full-width three-bay layout with three glass doors on the front and three on the back. Its 2265 L interior and nine shelves provide the greatest listed capacity in the series, supporting high-throughput cold-chain staging without combining all loads behind one opening. The stainless cabinet remains movable on four locking casters during installation or room reconfiguration.

Key Features

High-throughput frontage

Three independent door positions let users reach separate bays along the wide cabinet face.

Dense organized storage

Nine shelves distribute vaccine cartons, samples or production materials across clearly assigned zones.

Reduced cross-traffic

Front and rear access supports a receiving-to-controlled-area flow without personnel transfer.

Technical Parameters

Nominal Capacity	80 cu ft / 2265 L
Temperature Range	2–8 °C
External Dimensions	78 x 37.5 x 81.5 in
Internal Dimensions	75 x 30 x 59 in
Door Arrangement	Six keyed glass doors, three front and three back
Shelves	Nine
Construction	Stainless steel interior and exterior
Refrigerant	R290
Electrical	115 V, 60 Hz, single phase; 14.0 running A
Customization	Available based on the intended application and operating environment.

Applications

For high-throughput biobanks, vaccine stores and regulated production areas where multiple refrigerated loads must be staged and retrieved from opposite controlled sides.

Solutions for Your Application

Large transfer volumes overwhelm small cabinets and create frequent restocking cycles.Use the 2265 L three-bay interior to hold more material between scheduled transfers.

Users on opposite sides may disturb unrelated cold loads.Assign loads to separate bays and open only the corresponding keyed glass doors.

Available Options

Plan lock groups, shelf allocation, chart recorder or data logging, alarm outputs, access direction and wall closure trim. Verify circuit capacity for the listed 14.0 running amperes.

Planning a Refrigerated Pass Box 80 cu ft Straight-Through specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
