STjh 25 cubic foot pass-through refrigerator with one front glass door, three shelves and locking casters

STJH-REFRIGERATED-PASS-BOX-25CUFT-2TO8C

Refrigerated Pass Box 25 cu ft Straight-Through

A single-bay 707 L refrigerator providing secure cold access from opposite controlled aisles.

707 L single-bay capacity
One glass door on each face
2–8 °C storage range

Request a Quote Browse Products

Product Introduction

The 25 cu ft model is the compact member of the straight-through refrigerated series. One keyed glass door on each face gives staff on either side access to the same 707 L cold compartment without carrying products through a personnel route. Stainless steel interior and exterior surfaces, three shelves and locking casters support cleanable, flexible installation.

Key Features

Compact cold transfer

A 26 inch cabinet width fits locations that cannot accommodate multi-bay pass-through refrigerators.

Opposite-side visibility

Keyed glass doors let users check contents before opening from either controlled side.

Movable stainless cabinet

Four locking casters support positioning while the stainless body simplifies routine cleaning.

Technical Parameters

Nominal Capacity	25 cu ft / 707 L
Temperature Range	2–8 °C
External Dimensions	26 x 37.5 x 81.5 in
Internal Dimensions	23 x 30 x 59 in
Door Arrangement	Two keyed glass doors, one front and one back
Shelves	Three
Construction	Stainless steel interior and exterior
Refrigerant	R290
Electrical	115 V, 60 Hz, single phase; 4.2 running A
Customization	Available based on the intended application and operating environment.

Applications

For vaccines, temperature-sensitive samples and pharmacy stock moving between two controlled work aisles where a single refrigerated bay provides enough capacity.

Solutions for Your Application

Staff must preserve a cold chain while transferring items between adjacent controlled rooms.Provide access to one continuously refrigerated compartment from both sides.

Floor width is limited near the transfer boundary.Use the narrow 26 inch single-bay cabinet and organize loads across three shelves.

Available Options

Coordinate door swing, lock keying, alarm contacts, monitoring probes and wall trim. Four locking casters are included in the cited configuration.

Planning a Refrigerated Pass Box 25 cu ft Straight-Through specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.

Talk to Our Team
