STjh compact 610 by 610 by 915 mm HEPA pass-through storage cabinet with shelves and hanging rod

STJH-PASS-THROUGH-STORAGE-CABINET-610X610X915

Pass-Through Storage Cabinet 610 × 610 × 915 mm

A compact filtered pass-through cabinet for small supply packs and tools shared across a cleanroom partition.

610 x 610 mm compact footprint
HEPA-filtered vertical airflow
Adjustable shelf storage

Request a Quote Browse Products

Product Introduction

The 610 x 610 x 915 mm cabinet concentrates double-sided access and filtered storage in a compact wall footprint. A two-stage prefilter and HEPA air path can maintain vertical sweep around small consumable packs, while removable shelves let operators separate tools from folded garments. Its low height distinguishes it from the taller hanging-garment versions.

Key Features

Space-saving profile

The 915 mm overall height fits beneath services or work surfaces where a full-height cabinet is impractical.

Organized small-load storage

Adjustable shelves create separate levels for wrapped consumables, bins and hand tools.

Partition-side access

Doors on both sides allow supplies to be replenished without carrying them through the personnel route.

Technical Parameters

External Dimensions	610 W x 610 D x 915 H mm
Construction	304 or 316 stainless steel
Airflow Direction	Vertical filtered downflow
Average Air Velocity	0.45 ± 0.05 m/s
Filtration	Prefilter plus HEPA final filter
Storage Configuration	Removable adjustable shelves
Door Arrangement	Double-sided pass-through
Electrical Supply	220 V, 50 Hz typical
Intended Storage	Small cleanroom supplies and tools
Customization	Available based on the intended application and operating environment.

Applications

Suitable for wrapped gloves, wipes, small tools and folded garments passed between gowning support and a controlled room. It is most useful where storage volume is modest but operators need clean-side and service-side access.

Solutions for Your Application

A tall cabinet would obstruct utilities or consume unnecessary wall area.Choose the 915 mm-high format for compact loads and confirm shelf clearances against the largest package.

Mixing tools and consumables makes retrieval slow and increases handling.Arrange the removable shelves by load type and replenish each level from the support side.

Available Options

Choose 304 or 316 stainless steel, shelf spacing, hanging-rod substitution, door handing and filter monitoring. Final power and airflow settings can follow the room service standard.

Planning a Pass-Through Storage Cabinet 610 × 610 × 915 mm specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
