STjh wide 3000 mm multi-person air shower with open twin glazed doors, three bilateral nozzle banks and a floorless passage

STJH-MULTI-PERSON-AIR-SHOWER-1370X3000-60

Multi-Person Air Shower 1370 × 3000 mm 60-Nozzle

A wide three-metre chamber with 60 jets for high-throughput groups of up to eight people.

One-to-eight-person capacity
1370 x 3000 mm passage
60-nozzle high-throughput array

Request a Quote Browse Products

Product Introduction

This 1700 x 3000 x 2100 mm enclosure combines the widest and longest standard passage in this air-shower group. Its 1370 x 3000 x 1935 mm clear interior accommodates one to eight people, while 60 nozzles distribute cleaning air across the large occupied volume. It targets shift-change throughput rather than the single-file operation of the 770 mm models.

Key Features

Large group holding area

The wide three-metre passage contains up to eight occupants between the interlocked doors.

High-volume jet distribution

Sixty outlets spread cleaning air across multiple standing positions along both width and depth.

Shift-change efficiency

Group processing reduces repeated small cycles at heavily used personnel entrances.

Technical Parameters

Overall Dimensions	1700 x 3000 x 2100 mm
Internal Clearance	1370 x 3000 x 1935 mm
Maximum Occupancy	8 people
Nozzle Count	60
Air Delivery	Both side walls and ceiling
Passage Style	Wide straight-through
Floor Design	Floorless
Doors	Interlocked manual aluminium
Electrical Basis	AC 200 V, three phase, 50/60 Hz
Customization	Available based on the intended application and operating environment.

Applications

For high-throughput shift entrances, wide personnel routes and batch gown decontamination in electronics, life-science and precision-manufacturing facilities. Occupancy limits should reflect garments and required spacing.

Solutions for Your Application

Repeated two-person cycles create an entry bottleneck.Use the 1370 x 3000 mm holding area for a defined group of up to eight people.

A large group may block airflow to central occupants.Mark distributed standing locations that maintain open paths between the 60 nozzles and garment surfaces.

Available Options

Specify group cycle logic, occupancy indicators, door configuration, section joints, emergency release, lighting and finish. Fan and filter capacity should match the final nozzle layout.
