STJH-MEDIUM-PLEATED-PANEL-MERV15-100

Medium-Efficiency Pleated Panel Filter 100 mm MERV 15

The highest-efficiency four-inch model, engineered for demanding second-stage duty in depth-constrained AHUs.

MERV 15 compact rating
Rigid four-inch construction
Stable under variable airflow

Request a Quote Browse Products

Product Introduction

This model brings MERV 15 filtration to a 100 mm rigid panel. The supported moisture-resistant synthetic pleats are intended to tolerate variable-volume and turbulent HVAC conditions better than an unsupported media pad. It is selected where the full-depth alternatives cannot fit and where the finest grade in this compact series is needed before terminal filtration.

Key Features

Maximum compact-family efficiency

The MERV 15 grade provides the strongest fine-particle control available in this 100 mm series.

Turbulence-resistant assembly

Pleat supports reduce movement when fans start, stop or operate at changing volume.

Depth-saving final AHU stage

The slim rigid cell can occupy the last available filter track before remote terminal HEPA devices.

Technical Parameters

Nominal Depth	100 mm
Efficiency Rating	MERV 15
Filter Media	Moisture-resistant synthetic media
Pleat Support	Rigid stabilized construction
Frame Configuration	Box or single header
Maximum Operating Temperature	66 °C
Face Size Range	Standard full and fractional HVAC modules
Operating Mode	Suitable for variable and turbulent airflow
Intended Position	High-grade second-stage filtration
Customization	Available based on the intended application and operating environment.

Applications

Specified for clean manufacturing, healthcare support and laboratory supply systems that need high intermediate efficiency from a shallow cell. The model is useful when the air handler has no space for a 292 mm V-bank or rigid box filter.

Solutions for Your Application

The highest required intermediate grade is unavailable in the existing shallow cabinet.Use the 100 mm MERV 15 model when the track and fan-pressure allowance support the denser pack.

Repeated fan cycling causes media flutter and bypass risk.Pair the rigid stabilized cell with a correctly sized holding frame and continuous perimeter seal.

Available Options

Specify module dimensions, frame interface, gasket side and moisture exposure; verify that the fan can accommodate the selected loaded-filter limit.

Planning a Medium-Efficiency Pleated Panel Filter 100 mm MERV 15 specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
