STJH-LINEAR-SLOT-AIR-DIFFUSER-4S-25X1200

Linear Slot Air Diffuser Four-Slot 25 x 1200 mm

Broad four-slot linear diffuser for larger supply duties along a continuous ceiling section.

Four slots increase the available linear discharge width.
Separate pattern settings distribute air across larger zones.

Request a Quote Browse Products

Product Introduction

Four 25 mm passages form the widest selected 1200 mm body. Individually adjustable deflectors let the installer divide discharge among the slots, while the extruded aluminum rails keep the parallel openings aligned.

Key Features

Four slots increase the available linear discharge width.
Separate pattern settings distribute air across larger zones.

Technical Parameters

Slot Quantity	4
Individual Slot Width	25 mm
Nominal Section Length	1200 mm
Frame Material	Extruded aluminum
Pattern Deflectors	Individually adjustable
Deflector Finish	Matt black
Face Finish	White powder coat option
Supply Directions	Horizontal, vertical or intermediate
Volume Control Option	Integral balancing element
Customization	Available for the intended high-volume linear layout and operating environment.

Applications

Large support-space linear supply
Equipment-aisle comfort ventilation

Solutions for Your Application

A narrow single-slot section does not provide enough outlet width.

Four broad 25 mm passages expand the air-discharge interface within the same section length.

Available Options

Galvanized supply plenum
Alignment strips for continuous installation

Planning a Linear Slot Air Diffuser Four-Slot 25 x 1200 mm specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
