STjh 120 V laminar-flow transfer cart with two full-height doors, three perforated shelves and roof HEPA unit

STJH-LAMINAR-FLOW-TRANSFER-CART-2DOOR-120V

Laminar Flow Transfer Cart Two-Door 120 V

A full-height two-door filtered cart for transporting large sterile components through less-controlled corridors.

Two full-height access doors
Three perforated shelves
120 V fan-filter and backup power

Request a Quote Browse Products

Product Introduction

This 52.5 x 29.5 x 73 in cart uses two large doors to expose its full-height interior for bulky loads. Three perforated shelves allow filtered air to pass vertically around stored components, while a 120 V fan-filter and backup-power arrangement maintain circulation during transport. The large openings favor load capacity over the selective access provided by the six-door model.

Key Features

Large-load entry

Full-height doors simplify loading tall sterile assemblies and large closed containers.

Air-permeable storage

Perforated shelves let filtered air move between all three load levels.

Protected transport power

The 120 V system can use backup power to maintain airflow while the cart moves between outlets.

Technical Parameters

External Dimensions	52.5 W x 29.5 D x 73 H in
Door Count	Two full-height doors
Shelf Count	Three
Shelf Type	Perforated stainless
Electrical Supply	120 V
Air Treatment	Integrated filtered fan system
Backup Power	UPS configuration
Construction	Stainless steel cabinet
Intended Load	Large sterile components
Customization	Available based on the intended application and operating environment.

Applications

For moving large sterile components and assemblies through uncontrolled or lower-grade corridors. Define a charging location and maximum travel duration for the backup-power capacity.

Solutions for Your Application

Large loads cannot pass through compartment doors.Use the two full-height openings and adjust the perforated shelves around the load.

Filtered airflow stops while the cart is disconnected from mains power.Use the UPS arrangement and control route duration within its verified runtime.

Available Options

Select HEPA or ULPA filtration, shelf spacing, battery capacity, door interlock and monitoring. Caster brakes and handles can match the transport route.
