STJH-HEPA-GEL-CHANNEL-SILICONE

HEPA Filter Gel Seal Channel Silicone-Filled

A silicone fluid-seal channel for terminal HEPA and ULPA frames exposed to wider temperatures or repeated replacement.

Silicone fluid seal
Approximately -50 to 204 C gel range
Self-healing knife-edge interface

Request a Quote Browse Products

Product Introduction

This anodized aluminum channel uses silicone gel rather than polyurethane. The referenced gel family supports an approximately -50 to 204 C useful temperature range and forms a self-healing fluid interface around a ceiling or housing knife edge. The formulation suits terminal HEPA and ULPA frames needing repeated room-side changes, although silicone-sensitive processes should use the dedicated silicone-free urethane alternative.

Key Features

Wide thermal flexibility

Silicone gel remains compliant across a broader temperature range than many conventional foam gaskets.

Repeatable edge entry

The fluid seal closes around the knife edge after normal withdrawal and reinsertion.

Low-outgassing option

Selected silicone formulations support cleanroom terminal service where emission control is specified.

Technical Parameters

Gel Material	Silicone gel
Useful Gel Temperature Range	Approximately -50 to 204 C for the referenced family
Channel Material	Integral anodized aluminum
Seal Interface	Ceiling or housing knife edge
Seal Behavior	Self-healing fluid interface
Filter Compatibility	Terminal HEPA or ULPA frame
Service Access	Room-side filter replacement
Cleanliness	Low-outgassing formulation by selection
Application Limit	Not preferred for silicone-sensitive processes
Customization	Available based on the intended application and operating environment.

Applications

For pharmaceutical, healthcare and general cleanroom terminal filters requiring a reusable knife-edge gel seal over a broad operating range.

Solutions for Your Application

Silicone species are restricted near a sensitive coating or semiconductor process.Use the silicone-free urethane channel after confirming the process contamination specification.

Repeated knife-edge entry tears or contaminates the gel surface.Inspect the complete trough during every change and replace the filter when the gel no longer closes cleanly.

Available Options

Specify silicone formulation, channel geometry, filter grade, frame size, knife-edge height, temperature range and outgassing requirement.
