STJH-GEL-SEAL-HEPA-H14-VBANK-292

Gel-Seal HEPA Filter 292 mm H14 V-Bank

A deep H14 V-bank filter combining high airflow capacity with a positive gel-channel housing seal.

292 mm deep V-bank
H14 high-capacity filtration
0.50 in. gel channel

Request a Quote Browse Products

Product Introduction

This 292 mm H14 filter arranges multiple media packs in a V-bank housing to increase airflow capacity beyond a flat terminal panel. Its anodized aluminum frame includes a 0.50 in.-wide by 0.543 in.-deep gel channel, and available pack selections can reach approximately 2294 cfm. It is intended for air-starved HEPA housings that use a positive knife-edge fluid seal.

Key Features

High media area in one opening

Multiple angled packs increase effective filtration surface within a standard deep box footprint.

Positive fluid-seal interface

The dimensioned gel channel receives the housing knife edge to control perimeter bypass.

Airflow-oriented configuration

Pack selections support elevated volume where adding more HEPA bank openings is impractical.

Technical Parameters

Nominal Depth	292 mm
Efficiency Selection	H14 / 99.99% or better at 0.3 µm selection
Filter Geometry	Multi-pack V-bank
Frame Material	Anodized aluminum
Gel Channel Width	0.50 in.
Gel Channel Depth	0.543 in.
Maximum Referenced Airflow	Approximately 2294 cfm by pack selection
Housing Connection	Knife edge into continuous gel
Primary Duty	High-capacity final filtration
Customization	Available based on the intended application and operating environment.

Applications

Suitable for high-capacity final filtration in pharmaceutical, industrial and clean-process housings where available face area is limited. The deep V-bank requires adequate cabinet clearance, uniform upstream distribution and a knife edge matching the gel-channel geometry.

Solutions for Your Application

The HEPA housing cannot add more modules but needs greater airflow.The 292 mm V-bank increases media area behind each opening and offers pack selections up to about 2294 cfm.

A mismatched knife edge does not engage the gel channel correctly.Verify the housing edge against the 0.50 in. by 0.543 in. channel and inspect continuous penetration after installation.

Available Options

Confirm pack airflow, exact efficiency selection, gel compound, face dimensions, housing knife edge and installation clearance.
