STJH-FLUSH-CLEANROOM-WALL-ACCESS-PANEL-BALL-CATCH

Flush Cleanroom Wall Access Panel Ball-Catch Stainless Steel

A ball-catch door provides quick access to concealed cleanroom services.

Catch closure suits routine access points without keyed retention.
The closely fitted perimeter keeps the closed opening visually compact.

Request a Quote Browse Products

Product Introduction

A satin-polished stainless leaf sits within a shallow flush frame. The concealed hinge is available on either side, and an internal ball catch retains the closed leaf.

Key Features

Catch closure suits routine access points without keyed retention.
The closely fitted perimeter keeps the closed opening visually compact.

Technical Parameters

Material	304 or 316 stainless steel
Standard Opening Unit	400 x 325 mm, width x height
Alternative Unit Size	600 x 400 mm, width x height
Assembly Depth	45 mm
Steel Thickness Options	2 or 3 mm
Surface Finish	320-grit satin polish
Closure	Ball catch
Hinge	Fully concealed, left or right hand
Door Opening Angle	90 degrees
Customization	Available for the service opening and intended cleaning environment.

Applications

Frequently inspected valves behind cleanroom walls
Research-room service cupboards requiring simple catch access

Solutions for Your Application

Nearby equipment may obstruct the opened leaf.

Select left- or right-hand hinging around the available space for the 90-degree swing.

Aggressive rubbing could spoil the satin appearance.

Clean with mild detergent and a non-abrasive cloth, following the grain when polishing the satin surface.

Available Options

304 or 316 stainless steel
Left-hand or right-hand opening
400 x 325 mm or 600 x 400 mm unit

Planning a Flush Cleanroom Wall Access Panel Ball-Catch Stainless Steel specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
