STJH-COMPACT-MEDIUM-AIR-FILTER-EPM1-592

Compact Medium-Efficiency Air Filter 592 mm ePM1

A full-square ePM1 85% cassette providing the highest airflow capacity in this compact fine-filter pair.

592 mm full-module face
ISO ePM1 85%
4250 m3/h nominal capacity

Request a Quote Browse Products

Product Introduction

Using a 592 × 592 mm face and 292 mm depth, this hydrophobic microglass cassette delivers ISO ePM1 85% filtration at 4250 m3/h. Its clean pressure drop is 180 Pa, matching the efficiency family while more than doubling the airflow of the 287 mm half module. It is designed for standard full-size banks serving critical industrial and cleanroom supply systems.

Key Features

Full-bank utilization

The square 592 mm face fills a standard module opening without reducers or fractional blanking plates.

High ePM1 throughput

Hydrophobic microglass provides strong fine-particle control at more than twice the half-module airflow.

Rigid compact package

A 292 mm cassette protects the high-area media pack during installation and variable airflow service.

Technical Parameters

Overall Dimensions	592 × 592 × 292 mm
Efficiency Classification	ISO ePM1 85%
Rated Airflow	4250 m3/h
Clean Pressure Drop	180 Pa
Media Material	Hydrophobic microglass
Face Format	Full 592 mm square module
Cassette Depth	292 mm
Filter Construction	Rigid compact high-area pack
Service Role	Critical industrial intermediate filtration
Customization	Available based on the intended application and operating environment.

Applications

Suitable for critical manufacturing AHUs, pharmaceutical support ventilation and cleanroom recirculation banks built around standard full modules. The model is selected when high ePM1 efficiency and maximum airflow per opening are both required.

Solutions for Your Application

Too many fractional cells add joints and potential bypass paths across a full-size bank.Use the 592 mm square cassette to fill each full module with one sealed filter.

High ePM1 efficiency could reduce airflow below the process requirement.Size the fan using the 4250 m3/h rating and 180 Pa clean-filter pressure reference.

Available Options

Confirm face gasket, header arrangement, airflow direction and monitored final resistance for the full-module bank.

Planning a Compact Medium-Efficiency Air Filter 592 mm ePM1 specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
