A thin cut steel edge remains exposed along the track legs.
The 10 mm hems fold and close the upper edges.
STJH-CLEANROOM-WALL-BASE-CHANNEL-50-FIXED
Cleanroom Wall Base Channel 50 mm Folded-Steel Fixed
A folded galvanized-steel floor channel with hemmed legs for fixed 50 mm cleanroom wall bases.
- Folded hems finish both upper leg edges.
- Direct anchoring locates the wall base on the substrate.
- 3000 mm sections provide practical handling lengths.
Product Introduction
A 0.5 mm sheet is folded into a 50 x 50 x 50 mm channel. Both leg edges have 10 mm folded and crushed hems, while the base fixes directly to the floor. The panel enters the track and the two junctions can be sealed.
Key Features
- Folded hems finish both upper leg edges.
- Direct anchoring locates the wall base on the substrate.
- 3000 mm sections provide practical handling lengths.
Technical Parameters
| Channel Base Width | 50 mm |
|---|---|
| Leg Height | 50 mm |
| Sheet Thickness | 0.5 mm |
| Leg Hem | 10 mm folded and crushed |
| Maximum Length | 3000 mm |
| Material | Galvanized steel |
| Manufacturing Route | Sheet folding |
| Fixing | Direct floor anchoring |
| Sealing | Panel-to-channel and channel-to-floor sealant |
| Customization | Available for the intended application and operating environment. |
Applications
- Fixed cleanroom wall bases
- Demountable panel tracks on level substrates
Solutions for Your Application
The wall line needs positive restraint at floor level.
The channel base anchors directly to the supporting floor.
Available Options
- White polyester finish
- Panel-matching laminate finish
Planning a Cleanroom Wall Base Channel 50 mm Folded-Steel Fixed specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
