Cleanroom HEPA Supply Air Terminal 610 x 610 mm Ultra-Thin 600 m³/h

Compact 150 mm-deep terminal filter module for low-clearance cleanroom ceilings.

Square compact module fits local terminal filtration points.
Low body depth preserves space above the ceiling.

Request a Quote Browse Products

Product Introduction

The 610 mm square aluminum-profile frame holds glass-fibre filter media beneath a steel duct-connection top plate. Its shallow format connects a ducted supply directly to a terminal filtering face without an integral fan.

Key Features

Square compact module fits local terminal filtration points.
Low body depth preserves space above the ceiling.

Technical Parameters

External Dimensions	610 x 610 x 150 mm
Rated Airflow	600 m³/h
Initial Resistance	≤120 Pa
Particle Efficiency	≥99.9% at 0.3 µm
Frame Material	Aluminum profile
Top Plate	Steel
Filter Media	Glass-fibre paper
Media Separator	Hot-melt adhesive
Maximum Temperature	80 °C
Customization	Available for the intended ceiling arrangement and operating environment.

Applications

Low-clearance cleanroom terminal supply
Small local clean-air ceiling zones

Solutions for Your Application

A deep filter box cannot fit above the ceiling.

The 150 mm body provides a shallow ducted terminal configuration.

Available Options

Tailored duct-connection arrangement
Custom module dimensions

Planning a Cleanroom HEPA Supply Air Terminal 610 x 610 mm Ultra-Thin 600 m³/h specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
