STjh 3000 m3/h ceiling-mounted air handling unit with a large flat cabinet and reinforced suspension hardware on white.

STJH-CEILING-MOUNTED-AIR-HANDLING-UNIT-3000M3H

Ceiling-Mounted Air Handling Unit 3000 m3/h

The largest selected size-25 ceiling AHU, delivering approximately 3000 m3/h from a 288 kg corrosion-protected flat cabinet.

Approximately 3000 m3/h
Size-25 heavy-duty flat cabinet
C5-class casing protection

Request a Quote Browse Products

Product Introduction

This size-25 model reaches the documented 3000 m3/h family endpoint with larger dual recovery cores and fan modules. Its approximately 288 kg component package and C5-class casing protection suit a sizeable controlled floor, provided that structural suspension and maintenance access are designed for the larger cabinet.

Key Features

High ceiling-unit airflow

The enlarged fan and recovery components serve a large floor area without transferring equipment to occupied floor space.

Corrosion-protected enclosure

C5-class casing protection improves resilience where the ceiling plant zone sees humid or demanding service conditions.

Large dual-core recovery

The expanded counterflow arrangement recovers energy from a high-volume balanced ventilation stream.

Technical Parameters

Nominal Airflow Class	Approximately 3000 m3/h
Physical Size Class	25
Approximate Component Weight	288 kg
Heat Recovery	Large dual counterflow cores
Casing Corrosion Class	C5
Supply Filter	ePM1 class option
Extract Filter	ePM10 class option
Fan Type	High-capacity EC fan modules
Mounting	Engineered suspended ceiling support
Customization	Heating duty, filtration and mounting interfaces can be configured for the intended application and operating environment.

Applications

Large clean assembly floors, laboratory departments, controlled manufacturing support spaces and extensive ceiling-served ventilation zones.

Solutions for Your Application

The required airflow is too high for a small suspended unit, but floor plant space is unavailable.Use the size-25 platform with a structural suspension system designed for the 288 kg component package and accessories.

Humid ceiling conditions could degrade an ordinary casing finish.Apply the C5-class protected enclosure and control condensate at coils and duct interfaces.

Available Options

Water or electric heat, filter stages, frost protection, condensate accessories, pressure sensors, fan controls and building-system communication are available.
