Will a wide aluminum door become almost entirely glass?
The selected straight light occupies a limited area, leaving a broad opaque aluminum surround.
STJH-ALUMINUM-CLEANROOM-DOOR-1200-STRAIGHT-VISION
Aluminum Cleanroom Door 1200 mm Straight-Vision Aluminum-Faced
A broad 1200 mm clear-width aluminum-faced door retaining a straight rectangular observation light.
- A broad clear passage remains within a single-leaf arrangement.
- The compact straight light preserves more metal surface than half glazing.
- Metallic infill and perimeter construction create an aluminum-based blade structure.
Product Introduction
The broad blade uses prepainted aluminum skins and corrugated aluminum infill within an extruded perimeter frame. A straight rectangular viewing light occupies only part of the upper face, preserving a substantial opaque surround. The 1200 mm clear-width selection gives this single leaf different proportions from the narrower aluminum-door formats. Its conventional hinged movement suits an entrance with sufficient swing space and avoids the wall return needed for a sliding assembly.
Key Features
- A broad clear passage remains within a single-leaf arrangement.
- The compact straight light preserves more metal surface than half glazing.
- Metallic infill and perimeter construction create an aluminum-based blade structure.
Technical Parameters
| Clear Width | 1200 mm |
|---|---|
| Published Height | 2125 mm |
| Face Sheet | Prepainted aluminum |
| Face Sheet Thickness | 1.2 mm |
| Infill Construction | Corrugated aluminum |
| Internal Perimeter | 2 mm extruded aluminum profile |
| Glazing Pattern | Straight rectangular viewing light |
| Door Type | Single-leaf hinged |
| Operating Method | Manual |
| Customization | Available for the intended passage width and operating environment. |
Applications
- Wider laboratory entrances with room for a swing arc.
- Clean access routes needing limited observation through a broad blade.
Solutions for Your Application
Can a wide doorway use simple manual movement?
This configuration retains a conventional single hinged blade instead of adding a powered sliding mechanism.
Available Options
- Handing chosen for the available swing area.
- Door closer and compatible lever-handle options.
Planning a Aluminum Cleanroom Door 1200 mm Straight-Vision Aluminum-Faced specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
